ros 无线WDS MESH配置二（该方法简单好用）

AP1：config
/interface mesh
add name=wds_mesh
/interface ethernet
set [ find default-name=ether5 ] name=ether5-wan
/interface wireless
set [ find default-name=wlan1 ] band=2ghz-b/g/n
country=china disabled=no mode=ap-bridge name=AP1 \
radio-name=AP1 ssid=mesh
wds-default-bridge=wds_mesh wds-mode=dynamic-mesh
wps-mode=disabled
/interface mesh port
add interface=ether5-wan mesh=wds_mesh
add interface=AP1 mesh=wds_mesh
/system clock
set time-zone-name=Asia/Shanghai
/system identity set name=AP1
-------------------------------------------------
AP2:config
/interface mesh
add name=wds_mesh
/interface wireless
set [ find default-name=wlan1 ] band=2ghz-b/g/n
country=china disabled=no mode=\
ap-bridge name=AP2 radio-name=AP2 ssid=mesh
wds-default-bridge=wds_mesh \
wds-mode=dynamic-mesh wps-mode=disabled
/interface mesh port
add interface=AP2 mesh=wds_mesh
/system identity set name=AP2
-------------------------------------------------
AP3:config
/interface mesh
add name=wds_mesh
/interface wireless
set [ find default-name=wlan1 ] band=2ghz-b/g/n
country=china disabled=no mode=\
ap-bridge name=AP3 radio-name=AP3 ssid=mesh
wds-default-bridge=wds_mesh \
wds-mode=dynamic-mesh wps-mode=disabled
/interface mesh port
add interface=AP3 mesh=wds_mesh
/system identity set name=AP3
---------------------------------------------
AP4:config
/interface mesh
add name=wds_mesh
/interface wireless
set [ find default-name=wlan1 ] band=2ghz-b/g/n
country=china disabled=no mode=\
ap-bridge name=AP4 radio-name=AP4 ssid=mesh
wds-default-bridge=wds_mesh \
wds-mode=dynamic-mesh wps-mode=disabled
/interface mesh port
add interface=AP4 mesh=wds_mesh
/system identity set name=AP4

ros 无线WDS MESH配置二（该方法简单好用）

原文：https://www.cnblogs.com/itfat/p/12909808.html
