HDLBits做题记录 - Finite State Machines

Problem subset: Circuts\Sequential Logic\Finite State Machines.

Simple FSM 1 (asynchronous reset)

URL：Fsm1

Description

This is a Moore state machine with two states, one input, and one output. Implement this state machine. Notice that the reset state is B.

solution

1. determine "next state" by input in.
2. determine the sequential logic.

ref answer

module top_module (
	input clk,
	input in,
	input areset,
	output out
);

	// Give state names and assignments. I‘m lazy, so I like to use decimal numbers.
	// It doesn‘t really matter what assignment is used, as long as they‘re unique.
	parameter A=0, B=1;
	reg state;		// Ensure state and next are big enough to hold the state encoding.
	reg next;


    // A finite state machine is usually coded in three parts:
    //   State transition logic
    //   State flip-flops
    //   Output logic
    // It is sometimes possible to combine one or more of these blobs of code
    // together, but be careful: Some blobs are combinational circuits, while some
    // are clocked (DFFs).


    // Combinational always block for state transition logic. Given the current state and inputs,
    // what should be next state be?
    // Combinational always block: Use blocking assignments.
    always@(*) begin
		case (state)
			A: next = in ? A : B;
			B: next = in ? B : A;
		endcase
    end



    // Edge-triggered always block (DFFs) for state flip-flops. Asynchronous reset.
    always @(posedge clk, posedge areset) begin
		if (areset) state <= B;		// Reset to state B
        else state <= next;			// Otherwise, cause the state to transition
	end



	// Combinational output logic. In this problem, an assign statement is the simplest.
	// In more complex circuits, a combinational always block may be more suitable.
	assign out = (state==B);


endmodule

my answer

module top_module(
    input clk,
    input areset,    // Asynchronous reset to state B
    input in,
    output out);//

    parameter A=0, B=1;
    reg state, next_state;

    always @(*) begin    // This is a combinational always block
        // State transition logic
        case(in)
            1: next_state <= state; /* non-blocking is not appropriate here */
            0: next_state <= ~state;
        endcase
    end

    always @(posedge clk, posedge areset) begin    // This is a sequential always block
        // State flip-flops with asynchronous reset
        if(areset)begin
            state = B;
        end else begin
            state <= next_state;
        end
    end

    // Output logic
    // assign out = (state == ...);
    assign out = state;

endmodule

Warning (10230): Verilog HDL assignment warning at top_module.v(22): truncated value with size 32 to match size of target (1) File: /var/www/verilog/work/vlgVSQ7KV_dir/top_module.v Line: 22
Truncating values occur when the right side of an assignment is wider than the left side and the upper bits are cut off. This can indicate a bug if there is a truncation you didn‘t expect, so check these carefully. The most common case where this isn‘t a bug is when you‘re using literals without a width (32 bits is implied), e.g., using assign a[1:0] = 1; instead of assign a[1:0] = 2‘d1;.
