docker pull mysql:5.7

docker run --name mysql5.7 --restart always -p 3306:3306 -e MYSQL_ROOT_PASSWORD=123456 -d mysql:5.7

mysql -uroot -p123456 -P3306 -h192.168.0.176

create database nacos;

tar xf nacos-server-1.1.3.tar.gz

cp -a nacos-server-1.1.3.tar.gz nacos01
cp -a nacos-server-1.1.3.tar.gz nacos02
cp -a nacos-server-1.1.3.tar.gz nacos03

server.contextPath=/nacos
server.servlet.contextPath=/nacos
#修改端口，部署在一台上面应修改成不同端口，多台主机忽略次操作
server.port=8848

spring.datasource.platform=mysql

#设置mysql为存储库
db.num=1
db.url.0=jdbc:mysql://192.168.0.176:3306/nacos?characterEncoding=utf8&connectTimeout=1000&socketTimeout=3000&autoReconnect=true
db.user=root
db.password=123456

management.metrics.export.elastic.enabled=false

management.metrics.export.influx.enabled=false

server.tomcat.accesslog.enabled=true
server.tomcat.accesslog.pattern=%h %l %u %t "%r" %s %b %D %{User-Agent}i
server.tomcat.basedir=

nacos.security.ignore.urls=/,/**/*.css,/**/*.js,/**/*.html,/**/*.map,/**/*.svg,/**/*.png,/**/*.ico,/console-fe/public/**,/v1/auth/login,/v1/console/health/**,/v1/cs/**,/v1/ns/**,/v1/cmdb/**,/actuator/**,/v1/console/server/**

192.168.0.176:8846
192.168.0.176:8847
192.168.0.176:8848

#拷贝至nacos02
cp -a /data/nacos01/conf/application.properties /data/nacos02/conf/
cp -a /data/nacos01/conf/cluster.conf /data/nacos02/conf/cluster.conf

拷贝至nacos03
cp -a /data/nacos01/conf/application.properties /data/nacos03/conf/
cp -a /data/nacos01/conf/cluster.conf /data/nacos02/conf/cluster.conf

mysql -uroot -p123456 -P3306 -h192.168.0.176

use nacos;
source nacos-mysql.sql;

show tables;

vim /lib/systemd/system/nacos01.service

#nacos02 nacos03只需修改服务名称以及路径即可
[Unit]
Description=nacos01
After=network.target

[Service]
Type=forking
ExecStart=/data/nacos01/bin/startup.sh
ExecReload=/data/nacos01/bin/shutdown.sh
ExecStop=/data/nacos01/bin/shutdown.sh
PrivateTmp=true

systemctl start nacos01
systemctl enable nacos01

systemctl start nacos02
systemctl enable nacos02

systemctl start nacos03
systemctl enable nacos03

vim /etc/yum.repos.d/nginx.repo

[nginx]
name=nginx repo
baseurl=http://nginx.org/packages/centos/7/$basearch/
gpgcheck=0
enabled=1


yum install -y nginx-1.16.0

    include /etc/nginx/conf.d/*.conf;
    include /etc/nginx/conf.d/*.upstream;

#nacos.upstream
upstream nacos {
        #ip_hash;
        server 192.168.0.176:8846;
        server 192.168.0.176:8847;
        server 192.168.0.176:8848;
}

#nacos.conf
server {
    listen       8888;
    server_name  localhost;

    #charset koi8-r;
    access_log  /var/log/nginx/nacos.access.log  main;
    error_log  /var/log/nginx/nacos.error.log  ;

    #location ^~ /nacos {
    location / {
        proxy_pass   http://nacos;
        proxy_pass_header Server;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Scheme $scheme;
        proxy_set_header REMOTE-HOST $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    }
}

systemctl start nginx
systemctl enable nginx
