1 apiVersion: v1 2 kind: Namespace 3 metadata: 4 name: monitoring 5
1 apiVersion: rbac.authorization.k8s.io/v1beta1 2 kind: ClusterRole 3 metadata: 4 name: prometheus 5 rules: 6 - apiGroups: [""] 7 resources: 8 - nodes 9 - nodes/proxy 10 - services 11 - endpoints 12 - pods 13 verbs: ["get", "list", "watch"] 14 - apiGroups: 15 - extensions 16 resources: 17 - ingresses 18 verbs: ["get", "list", "watch"] 19 - nonResourceURLs: ["/metrics"] 20 verbs: ["get"] 21 --- 22 apiVersion: v1 23 kind: ServiceAccount 24 metadata: 25 name: prometheus 26 namespace: monitoring #修改命名空间 27 --- 28 apiVersion: rbac.authorization.k8s.io/v1beta1 29 kind: ClusterRoleBinding 30 metadata: 31 name: prometheus 32 roleRef: 33 apiGroup: rbac.authorization.k8s.io 34 kind: ClusterRole 35 name: prometheus 36 subjects: 37 - kind: ServiceAccount 38 name: prometheus 39 namespace: monitoring #修改命名空间 40
1 apiVersion: v1 2 kind: ConfigMap 3 metadata: 4 name: prometheus-server-conf 5 labels: 6 name: prometheus-server-conf 7 namespace: monitoring #修改命名空间 8 data: 9 prometheus.yml: |- 10 global: 11 scrape_interval: 10s 12 evaluation_interval: 10s 13 14 scrape_configs: 15 - job_name: ‘kubernetes-apiservers‘ 16 kubernetes_sd_configs: 17 - role: endpoints 18 scheme: https 19 tls_config: 20 ca_file: /var/run/secrets/kubernetes.io/serviceaccount/ca.crt 21 bearer_token_file: /var/run/secrets/kubernetes.io/serviceaccount/token 22 relabel_configs: 23 - source_labels: [__meta_kubernetes_namespace, __meta_kubernetes_service_name, __meta_kubernetes_endpoint_port_name] 24 action: keep 25 regex: default;kubernetes;https 26 27 - job_name: ‘kubernetes-nodes‘ 28 scheme: https 29 tls_config: 30 ca_file: /var/run/secrets/kubernetes.io/serviceaccount/ca.crt 31 bearer_token_file: /var/run/secrets/kubernetes.io/serviceaccount/token 32 kubernetes_sd_configs: 33 - role: node 34 relabel_configs: 35 - action: labelmap 36 regex: __meta_kubernetes_node_label_(.+) 37 - target_label: __address__ 38 replacement: kubernetes.default.svc:443 39 - source_labels: [__meta_kubernetes_node_name] 40 regex: (.+) 41 target_label: __metrics_path__ 42 replacement: /api/v1/nodes/${1}/proxy/metrics 43 44 - job_name: ‘kubernetes-cadvisor‘ 45 scheme: https 46 tls_config: 47 ca_file: /var/run/secrets/kubernetes.io/serviceaccount/ca.crt 48 bearer_token_file: /var/run/secrets/kubernetes.io/serviceaccount/token 49 kubernetes_sd_configs: 50 - role: node 51 relabel_configs: 52 - action: labelmap 53 regex: __meta_kubernetes_node_label_(.+) 54 - target_label: __address__ 55 replacement: kubernetes.default.svc:443 56 - source_labels: [__meta_kubernetes_node_name] 57 regex: (.+) 58 target_label: __metrics_path__ 59 replacement: /api/v1/nodes/${1}/proxy/metrics/cadvisor 60 61 - job_name: ‘kubernetes-service-endpoints‘ 62 kubernetes_sd_configs: 63 - role: endpoints 64 relabel_configs: 65 - source_labels: [__meta_kubernetes_service_annotation_prometheus_io_scrape] 66 action: keep 67 regex: true 68 - source_labels: [__meta_kubernetes_service_annotation_prometheus_io_scheme] 69 action: replace 70 target_label: __scheme__ 71 regex: (https?) 72 - source_labels: [__meta_kubernetes_service_annotation_prometheus_io_path] 73 action: replace 74 target_label: __metrics_path__ 75 regex: (.+) 76 - source_labels: [__address__, __meta_kubernetes_service_annotation_prometheus_io_port] 77 action: replace 78 target_label: __address__ 79 regex: ([^:]+)(?::\d+)?;(\d+) 80 replacement: $1:$2 81 - action: labelmap 82 regex: __meta_kubernetes_service_label_(.+) 83 - source_labels: [__meta_kubernetes_namespace] 84 action: replace 85 target_label: kubernetes_namespace 86 - source_labels: [__meta_kubernetes_service_name] 87 action: replace 88 target_label: kubernetes_name 89 90 - job_name: ‘kubernetes-services‘ 91 metrics_path: /probe 92 params: 93 module: [http_2xx] 94 kubernetes_sd_configs: 95 - role: service 96 relabel_configs: 97 - source_labels: [__meta_kubernetes_service_annotation_prometheus_io_probe] 98 action: keep 99 regex: true 100 - source_labels: [__address__] 101 target_label: __param_target 102 - target_label: __address__ 103 replacement: blackbox-exporter.example.com:9115 104 - source_labels: [__param_target] 105 target_label: instance 106 - action: labelmap 107 regex: __meta_kubernetes_service_label_(.+) 108 - source_labels: [__meta_kubernetes_namespace] 109 target_label: kubernetes_namespace 110 - source_labels: [__meta_kubernetes_service_name] 111 target_label: kubernetes_name 112 113 - job_name: ‘kubernetes-ingresses‘ 114 kubernetes_sd_configs: 115 - role: ingress 116 relabel_configs: 117 - source_labels: [__meta_kubernetes_ingress_annotation_prometheus_io_probe] 118 action: keep 119 regex: true 120 - source_labels: [__meta_kubernetes_ingress_scheme,__address__,__meta_kubernetes_ingress_path] 121 regex: (.+);(.+);(.+) 122 replacement: ${1}://${2}${3} 123 target_label: __param_target 124 - target_label: __address__ 125 replacement: blackbox-exporter.example.com:9115 126 - source_labels: [__param_target] 127 target_label: instance 128 - action: labelmap 129 regex: __meta_kubernetes_ingress_label_(.+) 130 - source_labels: [__meta_kubernetes_namespace] 131 target_label: kubernetes_namespace 132 - source_labels: [__meta_kubernetes_ingress_name] 133 target_label: kubernetes_name 134 135 - job_name: ‘kubernetes-pods‘ 136 kubernetes_sd_configs: 137 - role: pod 138 relabel_configs: 139 - source_labels: [__meta_kubernetes_pod_annotation_prometheus_io_scrape] 140 action: keep 141 regex: true 142 - source_labels: [__meta_kubernetes_pod_annotation_prometheus_io_path] 143 action: replace 144 target_label: __metrics_path__ 145 regex: (.+) 146 - source_labels: [__address__, __meta_kubernetes_pod_annotation_prometheus_io_port] 147 action: replace 148 regex: ([^:]+)(?::\d+)?;(\d+) 149 replacement: $1:$2 150 target_label: __address__ 151 - action: labelmap 152 regex: __meta_kubernetes_pod_label_(.+) 153 - source_labels: [__meta_kubernetes_namespace] 154 action: replace 155 target_label: kubernetes_namespace 156 - source_labels: [__meta_kubernetes_pod_name] 157 action: replace 158 target_label: kubernetes_pod_name 159
1 apiVersion: apps/v1beta2 2 kind: Deployment 3 metadata: 4 labels: 5 name: prometheus-deployment 6 name: prometheus-server 7 namespace: monitoring 8 spec: 9 replicas: 1 10 selector: 11 matchLabels: 12 app: prometheus-server 13 template: 14 metadata: 15 labels: 16 app: prometheus-server 17 spec: 18 containers: 19 - name: prometheus-server 20 image: prom/prometheus:v2.14.0 21 command: 22 - "/bin/prometheus" 23 args: 24 - "--config.file=/etc/prometheus/prometheus.yml" 25 - "--storage.tsdb.path=/prometheus/" 26 - "--storage.tsdb.retention=72h" 27 ports: 28 - containerPort: 9090 29 protocol: TCP 30 volumeMounts: 31 - name: prometheus-config-volume 32 mountPath: /etc/prometheus/ 33 - name: prometheus-storage-volume 34 mountPath: /prometheus/ 35 serviceAccountName: prometheus 36 imagePullSecrets: 37 - name: regsecret 38 volumes: 39 - name: prometheus-config-volume 40 configMap: 41 defaultMode: 420 42 name: prometheus-server-conf 43 - name: prometheus-storage-volume 44 emptyDir: {} 45
1 apiVersion: v1 2 kind: PersistentVolumeClaim 3 metadata: 4 name: prometheus-pvc 5 namespace: monitoring 6 annotations: 7 volume.beta.kubernetes.io/storage-class: ghstorageclass 8 spec: 9 accessModes: 10 - ReadWriteMany 11 resources: 12 requests: 13 storage: 5Gi
1 …… 2 - name: prometheus-storage-volume 3 persistentVolumeClaim: 4 claimName: prometheus-pvc 5 …… 6
1 --- 2 apiVersion: v1 3 kind: Service 4 metadata: 5 name: grafana 6 namespace: monitoring 7 labels: 8 app: grafana 9 spec: 10 type: NodePort 11 ports: 12 - port: 3000 13 targetPort: 3000 14 nodePort: 30007 15 selector: 16 app: grafana 17 --- 18 apiVersion: extensions/v1beta1 19 kind: Deployment 20 metadata: 21 labels: 22 app: grafana 23 name: grafana 24 namespace: monitoring 25 spec: 26 replicas: 1 27 revisionHistoryLimit: 2 28 template: 29 metadata: 30 labels: 31 app: grafana 32 spec: 33 containers: 34 - name: gragana 35 image: grafana/grafana:5.0.0 36 imagePullPolicy: IfNotPresent 37 ports: 38 - containerPort: 3000 39 volumeMounts: 40 - mountPath: /var 41 name: grafana-storage 42 env: 43 - name: GF_AUTH_BASIC_ENABLED 44 value: "false" 45 - name: GF_AUTH_ANONYMOUS_ENABLED 46 value: "true" 47 - name: GF_AUTH_ANONYMOUS_ORG_ROLE 48 value: Admin 49 - name: GF_SERVER_ROOT_URL 50 # value: /api/v1/proxy/namespaces/default/services/grafana/ 51 value: / 52 readinessProbe: 53 httpGet: 54 path: /login 55 port: 3000 56 volumes: 57 - name: grafana-storage 58 emptyDir: {} 59 nodeSelector: 60 node-role.kubernetes.io/master: "true" 61 # tolerations: 62 # - key: "node-role.kubernetes.io/master" 63 # effect: "NoSchedule" 64
050.集群管理-Prometheus+Grafana监控方案
