如何用纯 CSS 创作一个晃动的公告板

时间:2018-11-21 14:47:04      阅读:227      评论:0      收藏:0      [点我收藏+]

技术分享图片

效果预览

在线演示

按下右侧的“点击预览”按钮可以在当前页面预览,点击链接可以全屏预览。


https://codepen.io/comehope/pen/wjZoGV


可交互视频教程


此视频是可以交互的,你可以随时暂停视频,编辑视频中的代码。


请用 chrome, safari, edge 打开观看。


https://scrimba.com/c/cD8yKHb


源代码下载


本地下载

每日前端实战系列的全部源代码请从 github 下载:


https://github.com/comehope/front-end-daily-challenges


代码解读


定义 dom,容器中包含公告牌、挂公告牌的细绳和固定绳子的 3 个图钉:

<div class="signboard">
    <div class="sign">THANKS</div>
    <div class="strings"></div>
    <div class="pin top"></div>
    <div class="pin left"></div>
    <div class="pin right"></div>
</div>

居中显示:

html, body {
    width: 100%;
    height: 100%;
    display: flex;
    align-items: center;
    justify-content: center;
    background: radial-gradient(circle at center 60%, white, sandybrown);
}

定义公告牌的整体尺寸:

.signboard {
    width: 400px;
    height: 300px;
}

设置木板的样式:

.signboard {
    position: relative;
}

.sign {
    width: 100%;
    height: 200px;
    background: burlywood;
    border-radius: 15px;
    position: absolute;
    bottom: 0;
}

设置有雕刻效果的文字样式:

.sign {
    color: saddlebrown;
    font-family: sans-serif;
    font-weight: bold;
    text-align: center;
    line-height: 200px;
    text-shadow: 0 2px 0 rgba(255, 255, 255, 0.3),
                0 -2px 0 rgba(0, 0, 0, 0.7);
}

画出细绳:

.strings {
    width: 150px;
    height: 150px;
    border: 5px solid brown;
    position: absolute;
    border-right: none;
    border-bottom: none;
    transform: rotate(45deg);
    top: 38px;
    left: 122px;
}

画出细绳顶部的图钉:

.pin {
    width: 25px;
    height: 25px;
    border-radius: 50%;
    position: absolute;
}

.pin.top {
    background: gray;
    left: 187px;
}

画出木板上左右两侧的图钉:

.pin.left,
.pin.right {
    background: brown;
    top: 110px;
    box-shadow: 0 2px 0 rgba(255, 255, 255, 0.3);
}

.pin.left {
    left: 80px;
}

.pin.right {
    right: 80px;
}

最后,让告示牌晃动起来:
(此处已按 小蕾蕾 的建议修改为以顶部图钉作为旋转轴,比最初的效果要好)

.signboard {
    animation: swing 1.5s ease-in-out infinite alternate;
    transform-origin: 200px 13px;
}

@keyframes swing {
    from {
        transform: rotate(10deg);
    }

    to {
        transform: rotate(-10deg);
    }
}

大功告成!

原文地址:https://segmentfault.com/a/1190000014983030

如何用纯 CSS 创作一个晃动的公告板

原文:https://www.cnblogs.com/datiangou/p/9994326.html
